TS250RS Panel Saw 350 x 800mm Cast Iron Table Ø254mm Saw Blade & Includes 1250mm Sliding Table

NSW,QLD,VIC,WA - Delivers Nationally

TS250RS Panel Saw 350 x 800mm Cast Iron Table Ø254mm Saw Blade & Includes 1250mm Sliding Table :      $2,290 AUD ($2,519 Inc. GST)

  • Specifications
    Condition:
    New
    Type of Sale:
    In Stock
    Year:
    Not specified
    Make:
    Woodfast
    Model:
    TS250RS
    Electrical Phase:
    Single Phase
    Sliding Table Length:
    1250
    Sellers stock ID:
    W688
    Description

    WOODFAST TS250RS Panel Saw 350 x 800mm Cast Iron Table Ø254mm Saw Blade & Includes 1250mm Sliding Table
    CALL NOW AND DO A DEAL! ADD THIS ASSET TO YOUR WORKSHOP
    WE OFFER MACHINERY SOLUTIONS AT AFFORDABLE PRICES.
    Order Code: W688

    The backbone of any joinery workshop is having a great quality saw bench. The Woodfast TS250RS panel saw is a great example of that and is well known in the industry for its overall sturdiness, accuracy, powerful drive motor, reliable and simple to operate.

    The TS250RS panel saw has a hefty cast iron table with heavy gauge steel side extension table and the box section stand. The 254mm saw blade gives a cutting depth of up to 80mm at 90Ëš& 54mm at 45Ëš and adequately powered by a 1.5kW / 2hp - 240V 10-amp induction motor. Another useful feature is that is can cross cut up to 2280mm and incorporates a flip over stop for convenience whilst also allowing up to 610mm ripping capacity.

    The professional aluminium box extrusion sliding worktable can smoothly travel up to 1250mm in one motion with minimal friction of effort required. The cast iron table with right side extension support measures an attractive 1210 x 620mm in total. Dust can be removed via a 100mm dust port outlet at rear of machine and the saw guard when connected to a suitable high-volume extraction system.

    Features:
    254mm diameter saw blade with 45Ëš tilting arbor
    80mm @ 90º 54mm @ 45º depth of cut
    1.5kW / 2hp 240V motor
    Ideal for the serious home user who wants to accurately process solid wood but also has the need to rip larger sheets
    Professional aluminium sliding work table with 1250mm travel ensures smooth & minimal friction travel
    2280mm cross cut with adjustable flip over stop
    1200 x 238mm sliding table size
    350 x 800mm cast iron table (with steel extensions 620 x 1210mm)
    Rise and fall spindle
    610mm ripping capacity
    30mm dust extraction outlet on blade guard as well as a 100mm chute from the enclosed stand
    Includes heavy duty aluminium extrusion rip fence with fine adjustment


    Specifications:
    ORDER CODE: W688
    MODEL: TS250RS
    Blade Diameter (mm): Ø254
    Table Size (W x H) (mm): 350 x 800
    Table Size With Extensions (mm): 620 x 1210
    Max. Depth Of Cut 90º & 45º (mm): 80 / 54
    Scribe Blade Diameter (mm): ~
    Tilt Arbor To 45º: Yes
    Sliding Table Stroke (mm): 1250
    Cross Cut with Flip Over Stop (mm): 1230
    Cross Cut with Extension Stop (mm): 1230 - 2280
    Rip Capacity (mm): 610
    Motor Power (kW / hp): 1.5 / 2
    Voltage / Amperage (V / amp): 240 / 10
    Floor Space Required (W x D x H) (mm): 3150 x 2600 x 1150
    Shipping Dimensions (L x W x H) (mm): 1380 x 1180 x 940
    Weight (nett) (kg): 170
