EB-320DS Swivel Head-Dual Mitre Metal Cutting Band Saw Dual Mitre Cuts Up To 60º, Quick Action Mate

NSW,QLD,VIC,WA - Delivers Nationally

EB-320DS Swivel Head-Dual Mitre Metal Cutting Band Saw Dual Mitre Cuts Up To 60º, Quick Action Mate :      $5,750 AUD ($6,325 Inc. GST)

  • Specifications
    Condition:
    New
    Type of Sale:
    In Stock
    Year:
    Not specified
    Make:
    Hafco metalmaster
    Model:
    EB-320DS
    Sellers stock ID:
    B067
    Description

    HAFCO METALMASTER EB-320DS Swivel Head-Dual Mitre Metal Cutting Band Saw Dual Mitre Cuts Up To 60º, Quick Action Material Clamp & Includes Hydraulic Downfeed Control 310 x 205mm (W x H) Rectangle Capacity
    CALL NOW AND DO A DEAL! ADD THIS ASSET TO YOUR WORKSHOP
    WE OFFER MACHINERY SOLUTIONS AT AFFORDABLE PRICES.
    Order Code: B067

    Manufactured in Taiwan

    Features:
    310 x 205mm rectangular capacity
    Larger cutting capacity than conventional cold saws
    Heavy-duty gear drive system
    Ball bearing & carbide blade guides ensures minimal blade clearance wear and increases blade life due to less friction
    Blade cleaning brush incorporated into blade guide system
    Swivel head dual mitre cut to 45º right & left 60º right
    Quick action lock/release lever for swivel head
    Coolant system for cutting efficiency and blade life
    Material support roller for long stock
    Adjustable length stop for repetition cutting
    User friendly blade tension system with gauge
    Adjustable hydraulic cylinder for auto feed
    2-speed motor enabling blade speeds of 35 & 70mpm
    Vibration free low noise operation ensures clean & high precision cuts
    Machine stand with integrated cooling fitted as standard
    Quick-action lock/release vice
    Unique sliding vice design for dual mitre operation


    Specifications:
    ORDER CODE: B067
    MODEL: EB-320DS
    Operation Type: Swivel Head - Dual Mitre
    Operation Type: ~
    Round @ 90º (mm): 255
    Round @ 45º (mm): 220
    Round @ 60º (mm): 125
    Square @ 90º (mm): 205
    Square @ 45º (mm): 200
    Square @ 60º (mm): 125
    Rectangle (W x H) @ 90º (mm): 310 x 205
    Rectangle (W x H) @ 45º (mm): 205 x 200
    Rectangle (W x H) @ 60º (mm): 125 x 125
    Coolant System: Yes
    Table Working Height (mm): 950
    Cutting Head Beam Type: Manual
    Cutting Head Beam Return: Manual Return
    Cutting Head Down Feed Control: Adjustable Hydraulic
    Vice Clamping Fixture: Manual - Quick Action
    Bundle Cutting Fixture: ~
    Blade Steps / Speeds (m/min): 35-70
    Blade Size (L x W x T) (mm): 2750 x 27 x 0.9
    Motor Power (kW / hp): 1.5 / 2
    Voltage / Amperage (V / amp): 415
    Nett Weight (kg): 371
